Product Features
- Manual control for J type,PLC control for C/B type.
- Can set wrapping circles and wrapping position reinforcement,can reset automatically.
- Auto or manual work.
- Indicator alarms automatically.
- Photo electric for pallet height detecting.
- Can start、stop、locate freely.
- Can set wrapping position reinforcement at random.
- Remark:Pre-stretch film carriage,top platen,access ramp for optional,custom needs for over-height,over-weight,over-length are also available.
Product Specifications
| Model | JL2100-B | JL2100-C | JL2100-J |
| Working Type | Automatic | Automatic | Semi-Automatic |
| Turntable Power | 0.75KW | 0.75KW | 0.75KW |
| Film shelf Power | 0.4KW | 0.4KW | 0.4KW |
| Turntable Speed | 13r/min | 13r/min | 13r/min |
| Film Sheif Power | 3m/min | 3m/min | 3m/min |
| Turntable Diameter | 1500mm/1800mm | 1500mm/1800mm | 1500mm/1800mm |
| Turntable Height | 110mm | 110mm | 110mm |
| Tension Control | Magnetic Powder Machine | mechanical | mechanical |
| Height Control | Photoelectric | Photoelectric | Visual inspection |
| Turntable Start/Stop | Slow start/Slow stop | Slow start/Slow stop | Slow start/Slow stop |
| Max Packing Weight | 2000KG | 2000KG | 2000KG |
| Max Packing Height | 2000mm | 2000mm | 2000mm |
| Max Turning Diameter | 2000mm | 2000mm | 2000mm |
