Product Features
- Special double chain drive,oblique gear&worm speed reducer is adopted.
- Four-roller device wrapped with polyurethane.
- Inverter multi-speed control,smooth and safe.
- Independent control table allows remote operation.
- Multiple position limit system ensures safe operation.
- Machine can be stopped freely:the tilter locked in current position.
- Tilting by hydraulic,double backpressure safe and reliabale
- Reasonable hydraulic pipe layout,oil leak-proof design.
Product Specifications
| Model | FZ-03 | FZ-06 | FZ-08 | FZ-10 | FZ-15 | FZ-02-180 |
| Max Loading | 3T | 6T | 8T | 10T | 15T | 2T |
| Turning Time | 40s | 40s | 40s | 50s | 60s | 60s |
| Power Output | 0.75kw | 1.5kw | 2.2kw | 3.7kw | 5.5kw | 1.5kw |
| Power Voltage | 3 phase 380V | 3 phase 380V | 3 phase 380V | 3 phase 380V | 3 phase 380V | 3 phase 380V |
| Drive Mode | Mechanical/Hydraulic | Mechanical/Hydraulic | Mechanical/Hydraulic | Mechanical/Hydraulic | Mechanical/Hydraulic | Mechanical |
| Operation Mode | Manual switch/Wireless remote control | Manual switch/Wireless remote control | Manual switch/Wireless remote control | Manual switch/Wireless remote control | Manual switch/Wireless remote control | Manual switch/Wireless remote control |
